ADJUSTMENT INSTRUCTION
1. Application
1.1 This document is applied to LM80E chassis 32” LCD Monitor which is manufactured in Monitor Factory or is produced on the
basis of this data.
1.2 Manufacturing Type : Set
2. Designation
2.1 The adjustment is according to the order which is designated and which must be followed, according to the plan which can be
changed only on agreeing.
2.2. Power Adjustment: Free Voltage
2.3. Magnetic Field Condition: Nil.
2.4. Input signal Unit: Product Specification Standard
2.5. Reserve after operation: Above 5 Minutes (Heat Run)
Temperature : at 25℃±5°C
Relative humidity : 65 ±10%
Input voltage : 100 ~ 240V, 50/60Hz
2.6. Adjustment equipments: Color Analyzer (CA-210 or CA-110), DDC Adjustment Jig equipment,
3. Main PCB check process
* APC - After Manual-Insult, executing APC
3.1 ADC Process
1) 32UL950 doesn’t need ADC process because it has only digital input like TBT, DisplayPort and HDMI.
3.2 EDID Process
3.2.1 EDID Download
F/W includes default EDID for All input ports, aging on Mode If AC ON, default EDID is automatically loaded to EEPROM.
Update serial number in EDID of HDMI1.
☞ Caution: Never connect HDMI Cable when execute NVRAM Init and AC On at first for downloading HDMI EDID
automatically.
