PREPARATION
PREPARATION
20
STAND INSTRUCTIONS
(For 19/22LE5300, 22LE5500)
󰮌
Image shown may differ from your TV.
INSTALLATION
!
?
!
?
NOTE
When assembling the desk type stand,
make sure the screws are fully tightened (If
not tightened fully, the TV can tilt forward
after the product installation). Do not over
tighten.
1
Carefully place the TV screen side down
on a cushioned surface to protect the
screen from damage.
2
Assemble the parts of the STAND BODY
with the STAND BASE of the TV.
3
Assemble the TV as shown.
4
Install the 4 screws into the holes shown.
DETACHMENT
1
Carefully place the TV screen side down on
a cushioned surface to protect the screen
from damage.
2
Remove the screws from the TV.
3
Detach the stand from TV.
STAND BASE
STAND BODY
M4 x 14
