PREPARATION
PREPARATION
30
32/37/42/47LD450, 37/42/47LD450C, 32/42/47LD420, 32/42/47/55LD520, 55LD520C,
42/47/55LD630, 42/47LD451C, 32/37/42/47LD452C, 32/42/47LD452B, 26LD352C
CABLE MANAGEMENT
Image shown may differ from your TV.
1
Connect the cables as necessary.
To connect additional equipment, see the EXTERNAL EQUIPMENT SETUP section.
For 37/42/47LD450C, 55LD520C, 32/37/42/47LD452C, 32/42/47LD452B, 26LD352C:
Secure the power cord with the PROTECTIVE BRACKET/SCREW on the TV back cover. It will
help prevent the power cable from being removed by accident.
2
Open the CABLE MANAGEMENT CLIP as shown.
3
Put the cables inside the CABLE MANAGEMENT CLIP and snap it closed.
CABLE MANAGEMENT CLIP
PROTECTIVE BRACKET/SCREW
To Next Page
