62
10. Colour (Command:i)
G To adjust the screen colour.
You can also adjust colour in the Picture menu.
Transmission
Data Min: 0 ~ Max: 64 (transmit by Hexadecimal code)
• Refer to ‘Real data mapping 1’. See page 61.
[k][i][ ][Set ID][ ][Data][Cr]
Acknowledgement
[i][ ][Set ID][ ][OK][Data][x]
11. Tint (Command:j)
G To adjust the screen tint.(NTSC M input only)
You can also adjust tint in the Picture menu.
Transmission
Data Min: 0 ~ Max: 64 (transmit by Hexadecimal code)
• Refer to ‘Real data mapping 1’. See page 61.
[k][j][ ][Set ID][ ][Data][Cr]
Acknowledgement
[j][ ][Set ID][ ][OK][Data][x]
14. Key Lock (Command:m)
G To lock the front panel controls on the TV.
Transmission
[k][m][ ][Set ID][ ][Data][Cr]
Acknowledgement
Data 0: Lock off 1: Lock on
• If you’re not using the front panel controls on the TV, use
this mode. When main power is on/off, remote control
lock is released.
[m][ ][Set ID][ ][OK][Data][x]
16. Programme Select (Command:m a) (Main TV Input)
G Tune channel to following Physical/major/minor number.
T
ransmission
[m][a][ ][Set ID][ ][Data0][Cr]
Acknowledgement
[a][ ][Set ID][ ][OK][Data0][x]
[a][ ][Set ID][ ][NG][Data0][x]
G To adjust the screen sharpness.
You can also adjust sharpness in the Picture menu.
Transmission
12. Sharpness (Command:k)
Data Min: 0 ~ Max: 64 (transmit by Hexadecimal code)
• Refer to ‘Real data mapping 1’. See page 61.
[k][k][ ][Set ID][ ][Data][Cr]
Acknowledgement
[k][ ][Set ID][ ][OK][Data][x]
13. OSD Select (Command:l)
G To select OSD (On Screen Display) mute on/off.
Transmission
[k][l][ ][Set ID][ ][Data][Cr]
Acknowledgement
Data 0: OSD mute on 1: OSD mute off
[l][ ][Set ID][ ][OK][Data][x]
Data0: Programme Number
Min : 0 ~ Max : 63(transmit by Hexadecimal code)
18. Key (Command:m c)
G To send IR remote key code.
T
ransmission
[m][c][ ][Set ID][ ][Data][Cr]
Acknowledgement
[c][ ][Set ID][ ][OK][Data][x]
Data: Key code (Refer to P.58)
17. Programme Select (Command:m b) (Sub TV Input)
G Tune channel to following Physical/major/minor number.
T
ransmission
[m][b][ ][Set ID][ ][Data 0][Cr]
Acknowledgement
[b][ ][Set ID][ ][OK][Data0][x]
[b][ ][Set ID][ ][NG][Data0][x]
Data0: Programme Number
Min : 0 ~ Max : 63(transmit by Hexadecimal code)
09. Brightness (Command:h)
G To adjust screen brightness.
You can also adjust brightness in the Picture menu.
Transmission
Data Min: 0 ~ Max: 64 (transmit by Hexadecimal code)
• Refer to ‘Real data mapping 1’. See page 61.
[k][h][ ][Set ID][ ][Data][Cr]
Acknowledgement
[h][ ][Set ID][ ][OK][Data][x]
15. Balance (Command:t)
G To adjust balance.
Transmission
[k][t][ ][Set ID][ ][Data][Cr]
Acknowledgement
Data Min: 0 ~ Max: 64 (transmit by Hexadecimal code)
• Refer to ‘Real data mapping 1’. See page 61.
[t][ ][Set ID][ ][OK][Data][x]
External Control Device Setup ; RS-232C
External Control Device Setup ; RS-232C
Reference
Reference
