LG 32PC51 - PC Setup and Screen Configuration

20
EXTERNAL EQUIPMENT SETUP
PC SETUP
EXTERNAL EQUIPMENT SETUP
This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.
When connecting with a D-sub 15 pin cable
RGB IN(PC)
AUDIO IN
(RGB/DVI)
VARIABLE
OUT
AV 2 AV 1
RGB OUTPUT
AUDIO
Connect the RGB output of the PC to the
RRGGBB
II NN
((
PPCC
))
jack on the set.
Connect the PC audio output to the
AAUUDDIIOO IINN
((RRGGBB//DDVVII))
jack on the set.
Turn on the PC and the set.
Select
RGB PC input source with using the
IINNPPUUTT
button on the remote control.
2
3
4
1
1
2
