LG 32SQ780S

7
How to fix a clamp
1 After positioning the stand on the table, secure it by turning the handle.
• For tables without a protrusion
- The table should be less than 75mm (2.9inches) thick.
Table
≤ 75mm (2.9inches)
• Stands that are not fully engaged to the table may allow the monitor to wobble or fall over.
• Make sure the table is solid and stable enough to fully support installation of the monitor. Tables made of fragile materials such as glass may break.
• For tables with a protrusion
- If the protrusion is located more than 95mm (3.7inches) away from the edge of the table, install the monitor only when a flat protrusion is located
between 10mm (0.39inches) to 75mm (2.9inches) from the edge of the table.
≥ 95mm
(3.7inches)
≥ 75mm
(2.9inches)
10mm
(0.39inches)
Swivel stand
Swivel the monitor left and right within 280° to fit your view.
• When swiveling the monitor screen, be careful not to get your fingers caught or bumped into the stand.
