LG 32SQ780S

8
Pivot Feature
The pivot feature allows the monitor to rotate 90° counter-clockwise.
Monitor’s head
Table
• When using the Pivot function, do not rotate the monitor too fast or with excessive force. The table may be scratched by contact with the monitor’s head.
1 Raise the monitor up to the maximum height. 2 Adjust the angle of the monitor in the direction of the arrow as shown
in the figure.
3 Rotate the monitor counter-clockwise as shown in the figure. 4 Complete the installation by rotating the monitor 90° as shown in the
figure.
