EXTERNAL CONTROL DEVICE SETUP
Command reference list
Communication Parameters
y Baud rate: 9600 bps (UART)
y Data length: 8 bits
y Parity : None
y Stop bit: 1 bit
y Communication code: ASCII code
y Use a crossed (reverse) cable.
y Note : During USB operations such as DivX or EMF, all commands except Power(ka) and Key(mc)
are not executed and treated as NG.
COMMAND1 COMMAND2
DATA
(Hexadeci-
mal)
COMMAND1 COMMAND2
DATA
(Hexadeci-
mal)
01. Power k a 00 to 01 14. Bass k s 00 to 64
02. Aspect
Ratio
k c (See p.150) 15. Balance k t 00 to 64
03. Screen
Mute
k d (See p.150)
16. Colour
Temperature
x u 00 to 64
04. Volume
Mute
k e 00 to 01
17. Energy
Saving
j q 00 to 05
05. Volume
Control
k f 00 to 64
18. Auto Con-
figuration
j u 01
06. Contrast k g 00 to 64
19. Tune Com-
mand
m a (See p.152)
07. Brightness k h 00 to 64
20. Programme
Add/Skip
m b 00 to 01
08. Colour k i 00 to 64 21. Key m c Key Code
09. Tint k j 00 to 64
22. Control
Back Light
m g 00 to 64
10. Sharpness k k 00 to 64
23. Input select
(Main)
x b (See p.153)
11. OSD Select k l 00 to 01 24. 3D x t (See p.154)
12. Remote
Control Lock
Mode
k m 00 to 01
25. Extended
3D
x v (See p.154)
13. Treble k r 00 to 64
To Next Page
