4. Signal Timing (Supporting Resolution)
No. Section Pol. Dot Clock
[MHz]
Frequency
[kHz]/[Hz]
Total
Cycle
(E)
Display
(A)
Front
Porch(B)
Sync.
(D)
Back
Porch(F)
Resolution
1 H(Pixels) - 25.175 31.469 800 640 16 96 48 640 x 480
V(Lines) - 59.94 525 480 10 2 33
2 H(Pixels) - 31.5 37.5 840 640 16 64 120 640 x 480
V(Lines) - 75 500 480 1 3 16
3 H(Pixels) - 28.321 31.468 900 720 18 108 54 720 X 400
V(Lines) + 70.8 449 400 12 2 35
4 H(Pixels) + 40 37.879 1056 800 40 128 88 800 x 600
V(Lines) + 60.317 628 600 1 4 23
5 H(Pixels) + 49.5 46.875 1056 800 16 80 160 800 x 600
V(Lines) + 75 625 600 1 3 21
6 H(Pixels) +/- 57.283 49.725 1152 832 32 64 224 832 x 624
V(Lines) +/- 74.55 667 624 1 3 39
7 H(Pixels) - 65 48.363 1344 1024 24 136 160 1024 x 768
V(Lines) - 60 806 768 3 6 29
8 H(Pixels) - 78.75 60.023 1312 1024 16 96 176 1024 x 768
V(Lines) - 75.029 800 768 1 3 28
9 H(Pixels) - 81.75 53.783 1520 1152 64 120 184 1152 x 864
V(Lines) + 59.959 897 864 3 4 26
10 H(Pixels) + 74.25 45 1650 1280 110 40 220 1280 x 720
V(Lines) + 60 750 720 5 5 20
11 H(Pixels) + 108 63.981 1688 1280 48 112 248 1280 x 1024
V(Lines) + 60.02 1066 1024 1 3 38
12 H(Pixels) + 135 79.98 1688 1280 16 144 248 1280 x 1024
V(Lines) + 75.02 1066 1024 1 3 38
13 H(Pixels) + 85.5 47.712 1792 1360 64 112 256 1360 x 768
V(Lines) + 60.015 795 768 3 6 18
14 H(Pixels) + 108 60 1800 1600 24 80 96 1600 x 900
V(Lines) + 60 1000 900 1 3 96
15 H(Pixels) - 146.25 65.29 2240 1680 104 176 280 1680 x 1050
V(Lines) + 59.954 1089 1050 3 6 30
16 H(Pixels) + 148.5 67.5 2200 1920 88 44 88 1920 x 1080
+ 60 1125 1080 4 5 46
4.1. RGB (PC Mode)
