4.2. HDMI, Display Port (PC Mode )
4.3. HDMI, Display Port (DTV Mode)
No.
Specication Remark
Resolution H-freq(kHz) V-freq(Hz) Proposed
1 31.5 60 EDTV 480p 480/60P
2 31.25 50 EDTV 576p 576/50P
3 37.5 50 HDTV 720p 720/50P
4 45 60 HDTV 720p 720/60P
5 28.1 50 HDTV 1080i 50Hz 1080/50i
6 33.75 60 HDTV 1080i 60Hz 1080/60i
7 56.25 50 HDTV 1080P 50Hz 1080/50P
8 67.432 59.94 HDTV 1080P 60Hz 1080/60P
9 67.5 60 HDTV 1080P 60Hz 1080/60P
10 54 24 UDTV 2160P 24Hz 2160/24P
11 56.25 25 UDTV 2160P 25Hz 2160/25P
12 67.5 30 UDTV 2160P 30Hz 2160/30P
No. Section Pol. Dot Clock
[MHz]
Frequency
[kHz]/[Hz]
Total
Cycle
(E)
Display
(A)
Front
Porch(B)
Sync.
(D)
Back
Porch(F)
Resolution
1 H(Pixels) - 25.175 31.469 800 640 16 96 48 640 x 480
V(Lines) - 59.94 525 480 10 2 33
2 H(Pixels) + 40 37.879 1056 800 40 128 88 800 x 600
V(Lines) + 60.317 628 600 1 4 23
3 H(Pixels) - 65 48.363 1344 1024 24 136 160 1024 x 768
V(Lines) - 60 806 768 3 6 29
4 H(Pixels) - 81.75 53.783 1520 1152 64 120 184 1152 x 864
V(Lines) + 59.959 897 864 3 4 26
5 H(Pixels) + 74.25 45 1650 1280 110 40 220 1280 x 720
V(Lines) + 60 750 720 5 5 20
6 H(Pixels) - 83.5 49.702 1680 1280 72 128 200 1280 X 800
V(Lines) + 59.81 831 800 3 6 22
7 H(Pixels) + 85.5 47.712 1792 1366 70 143 213 1366 x 768
V(Lines) + 59.79 798 768 3 3 24
8 H(Pixels) + 108 63.981 1688 1280 48 112 248 1280 x 1024
V(Lines) + 60.02 1066 1024 1 3 38
9 H(Pixels) + 108 60 1800 1600 24 80 96 1600 x 900
V(Lines) + 60 1000 900 1 3 96
10 H(Pixels) - 146.25 65.29 2240 1680 104 176 280 1680 x 1050
V(Lines) + 59.954 1089 1050 3 6 30
11 H(Pixels) + 148.5 67.5 2200 1920 88 44 88 1920 x 1080
V(Lines) + 60 1125 1080 4 5 46
12 H(Pixels) + 154 74.038 2080 1920 48 32 80 1920 x 1200
V(Lines) - 59.95 1235 1200 3 6 26
13 H(Pixels) + 297 67.5 4400 3840 176 88 296 3840 x 2160
H(Pixels) + 30 2250 2160 8 10 72
