Installing on the ceiling
(Only for 55EG5CD model)
When installing, do not install more than 30 cm away from the ceiling for safe cable connection.
CAUTION
• Disconnect the power cord before moving or installing the monitor to avoid risk of electric shock.
• Use a stainless steel wire rope that can bear enough weight (100 kgf or above). (Sold separately)
• If you are using an installation accessory, make sure that you use a stainless steel wire rope that is 2 mm in diameter.
- Use a press for compression when using a crimp sleeve. If not, the wire may fall out.
NOTE
• The illustration shows a general example of installation and may look different from the actual product.
• The distance from the ceiling may be 30 cm or less after installation depending on the state of the ceiling.
30 cm or less
2 mm Diameter Stainless Steel Wire Rope
Crimp sleeve
