ENGLISH
27
PRODUCT SPECIFICATIONS
The product specifications below may be changed without prior notice due to upgrade of product functions.
“ ” refers to alternating current (AC), and “ ” refers to direct current (DC).
OLED screen Screen type Thin Film Transistor (TFT)
OLED Screen
Operating conditions Daily usage 18 hours (video)
Video signal Maximum resolution HDMI / DisplayPort: 3840 x 2160 @ 30 Hz
OPS: 1920 x 1080 @ 60 Hz
- This may not be supported on some OS or graphics card
types.
Recommended resolution HDMI / DisplayPort / OPS: 1920 x 1080 @ 60 Hz
- This may not be supported on some OS or graphics card
types.
Horizontal frequency HDMI/ DisplayPort/ OPS: 30 kHz to 83 kHz
Vertical frequency HDMI/ DisplayPort/ OPS: 50 Hz to 60 Hz
Synchronization Separate/Digital
Input/ Output ports Panel Out, USB 2.0 IN, HDMI, DP IN, DP OUT, USB 3.0 IN, LAN IN, LAN OUT, IR IN, RS-232C
IN/OUT, AUDIO OUT
Embedded battery Applied
Environmental
Conditions
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity 10 % to 80 %
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Humidity 5 % to 85 %
OLED Panel Pixel Pitch 0.630 mm (H) X 0.630 mm (V)
Power Rated Voltage AC 100-240 V ~ 50/60 Hz 3.0 A
Power Consumption On Mode: 190 W (Typ.)
Sleep Mode (HDMI, DisplayPort): ≤ 3.0 W
Off Mode: ≤ 0.5 W
Dimensions (Width
x Height x Depth) /
Weight
Display 1227 mm x 702.1 mm x 3.65 mm / 5.5 kg
(48.3 inches x 27.6 inches x 0.1 inches / 12.1 lbs)
Signage Box 420 mm x 75 mm x 230 mm / 5.3 kg
(16.5 inches x 2.9 inches x 9.0 inches / 11.6 lbs)
