LG 55LS4500 - Component Connection

ENGLISH
62
MAKING CONNECTIONS
VIDEO
Y
PB
PR
RL
VIDEO AUDIO
L/MONO AUDIO
COMPONENT IN
AV IN
R
AUDIO
VIDEO
L R
DVD / Blu-Ray / HD Cable Box
GREEN
GREEN
BLUE
BLUE
RED
RED
WHITE
WHITE
RED
RED
(*Not Provided) (*Not Provided)
Component Connection
Transmits the analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the component cable as shown in the following illustration.

If cables are installed incorrectly, it could case the image to display in black and white or with
distorted color.

Check to ensure the cable are matched with the corresponding color connection.
NOTE
