Composite Connection
Transmits the analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the composite cable as shown in the following illustration.

If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of the
TV.
