LG ARWN072BA2 - Outside Units Information

Outside units Information
8 Outside Unit
Outside units Information
Power Supply: Outside Unit (3Ø, 208/230V, 60Hz)
n Heat pump
• Ratio of the running Indoor Units to the Outside: Within 10 ~ 100%
• A combination operation over 100% cause to reduce each indoor unit capacity.
n Combination Ration(50~200%)
Notes:
* We can guarantee the operation only within 130% Combination.
If you want to connect more than 130% combination, please contact us and discuss the require-
ment like below.
1) If the operation of indoor unit is more than 130%, low airflow operation is recommended in all
the indoor units.
2) If the operation of indoor unit is more than 130%, additional refrigerant is needed according to
the Äheadquarter guidance.
3)Over 130%, capacity is same as capacity of 130%, Same remark is valid for power input.
Outside Number Connection Capacity
Single outside units 200%
Double outside units 160%
Triple outside units 130%
System Capacity HP(Ton)
Model Name
Product Refrigerant Charge (kg(lb))
CF(Correction Factor) (kg(lb))
Maximum Connectable No. of Indoor Units
Net Weight kg
lb
Dimensions(WxHxD) mm
inch
Refrigerant Liquid mm(inch)
Connecting Pipes Gas mm(inch)
Water Inlet mm
Connecting Pipes Outlet mm
Drain Outlet mm(inch)
8(6.5) 16(12.5) 24(19.0)
ARWN072BA2 ARWN144BA2 ARWN216BA2
7.3(16.1) 8.8(19.4) 8.8(19.4) + 7.3(16.1)
---
13 26 39
170 238 238 + 170
374.8 524.7 524.7 + 374.8
772x1,120x547 772x1,120x547 (772x1,120x547) x 2
30.4x44.1x21.5 30.4x44.1x21.5 (30.4x44.1x21.5) x 2
9.52(3/8) 12.7(1/2) 19.05(3/4)
22.2(7/8) 28.58(1 1/8) 34.9(1 3/8)
PT32A PT40A PT40A + PT32A
PT32A PT40A PT40A + PT32A
20(3/4) 20(3/4) 20(3/4)
