FUNCTIONAL SPECIFICATIONS AC Smart BACnet
Objects - AC Smart BACnet /IP
BACnet Point List : Indoor Unit
One indoor unit has a Point List as follows.
Some of IDU Points may not be supported depending on the product.
Point
No.
Control/monitoring
Object Name
(XXX : Unit address)
Object
Type
Unit
Inactive Active
Text- 0 Text-1
Text-2 Text- 3 Tex t- 4 Text- 5
1 ON/OFF (Setting)
StartStopCommand_
XXX
BO Stop Start
2 ON/OFF (Status) StartStopStatus_XXX BI Stop Run
3 Lock (Setting) LockCommand_XXX BO Permit Prohibit
4 Lock (Status) LockStatus_XXX BI Permit Prohibit
5 Filter Sign Filter Sign_XXX BI Off On
6 Filter Sign Reset
Filter Sign Reset_
XXX
BV - Reset
7 Operation Mode (Setting) ModeCommand_XXX MO Cool Dry Fan Auto Heat
8 Operation Mode (Status) ModeStatus_XXX MI Cool Dry Fan Auto Heat
9 Swing (Setting)
SwingCommand_
XXX
BO Stop Run
10 Swing (Status) SwingStatus_XXX BI Stop Run
11 Fan Speed (Setting)
FanSpeedCommand_
XXX
MO Low Middle High Auto
12 Fan Speed (Status)
FanSpeedStatus_
XXX
MI Low Middle High Auto
13 Set Room Temperature SetRoomTemp _ X X X AV °C
14 Room Temperature RoomTemp _ X XX AI °C
15 Alarm Alarm_XXX BI Normal Abnormal
