FUNCTIONAL SPECIFICATIONS AC Smart BACnet
FUNCTIONAL SPECIFICATIONS
AC Smart BACnet
Summary
The AC Smart BACnet , in response to the requests from the BMS (Building management system
which supports BACnet-ANSI/ASHRAE135 protocol), status information of A/C/vent that are
connected to the AC Smart BACnet ’s internal LG-NET will be sent in BACnet service form, and
BACnet client provides a function that transmits control command to the A/C/vent system.
Configuration of Connection
A BACnet client that supports BACnet-ANSI/ASHRAE135 protocol allows direct connection via
generally used HUBs or Ethernet. The image of its connection configuration is as shown below.
PQNFB17C
AC Smart
BACnet
