FUNCTIONAL SPECIFICATIONS AC Smart BACnet
Function Code : 0x03
Register Function Name
Object Name
(XXX : AHU address)
Text- 0 Text-1 Text-2 Text-3 Text- 4 Tex t- 5
1
Read
Holding
Registers
MODE ModeStatus_XXX
Cool Dry Fan
POWSAV
Heat
2 SET TEMP SetTempStatus_XXX
°C
3 SUPPLY TEMP SupplyTempStatus _ XX X
-127~127
4 OUTDOOR TEMP OutdoorTempStatus_XXX
-127~127
5 VENT TEMP VentTempStatus_XXX
-127~127
6 MIXING TEMP MixingTempStatus_XXX
-127~127
7 SET HUMIDITY SetHumidityStatus_XXX
40~60
8 SUPPLY HUMIDITY SupplyHumidityStatus_XXX
30~90
9 OUTDOOR HUMIDITY OutdoorHumidityStatus_XXX
30~90
10 VENT HUMIDITY VentHumidityStatus_XXX
30~90
11 CO2 VALUE CO
2
ValueStatus_XXX
0~255
12 ERROR CODE MalfunctionCode_XXX Reference LG original Error Code
17 CURR_OA_DAMPER CurOADamperStatus_XXX
0~90
18 CURR_EA_DAMPER CurEADamperStatus_XXX
0~90
19 CURR_MIX_DAMPER CurMixDamperStatus_XXX
0~90
20 COOL_OA_DAMPER OADamperCoolStatus_XXX
0~90
21 COOL_EA_DAMPER EADamperCoolStatus_XXX
0~90
22 COOL_MIX_DAMPER MixDamperCoolStatus_XXX
0~90
23 HEAT_OA_DAMPER OADamperHeatStatus_XXX
0~90
24 HEAT_EA_DAMPER EADamperHeatStatus_XXX
0~90
25 HEAT_MIX_DAMPER MixDamperHeatStatus_XXX
0~90
