FUNCTIONAL SPECIFICATIONS AC Smart BACnet
Local Definition of Object ID - The instance number is a pair, this consists of the indoor unit No. and
item.
Example of Point Table
The point table below is passed to BMS, and BMS registers the object.
Object Type Instance Number
0516191
0341112 751 8
Device No.
(from 0 to 16)
Product Unit No.
(from 0 to 16)
Point No.
(from 0 to 16)
* Object Type (Coil : 0, Register : 4)
* Product Type (Indoor : 0, Vent : 4, AHU : 8)
** Device : Group of Product units (16EA)
Product Type
Address
Case Indoor
Function Code Device No. Product No. Point Instance No. Name
1 0 0 0 0x00000 ON/OFF status
5 0 0 0 0x00000 ON/OFF Setting
1 0 1 0 0x00010 ON/OFF status
5 0 1 0 0x00010 ON/OFF Setting
1 1 0 0 0x00100 ON/OFF status
5 1 0 0 0x00100 ON/OFF Setting
3 0 0 0 0x40000 Mode status
6 0 0 0 0x40000 Mode Setting
3 0 1 0 0x40010 Mode status
6 0 1 0 0x40010 Mode Setting
3 1 0 0 0x40100 Mode status
6 1 0 0 0x40100 Mode Setting
