19Installation
Installation
3
Connecting to an Amplifi er via
Digital Audio Output
Connect the player’s DIGITAL AUDIO OUT jack
to the corresponding in jack (COAXIAL) on your
ampli er. Use an optional digital audio cable.
You will need to activate the player’s digital
output. (See “[AUDIO] Menu” on pages 27-28.)
Digital Audio Connection
Coaxial
cable
Receiver/Ampli er
BD Player
Connecting to an Amplifi er via
2 Channel Audio Output
Connect the Left and Right 2CH AUDIO OUT
jacks on the player to the audio left and right
in jacks on your ampli er, receiver, or stereo
system using audio cables.
2CH Analog Audio Connection
Audio cable
Receiver/Ampli er
BD Player
