LG BP340 Service Manual

3-8
ELECTRICAL TROUBLESHOOTING GUIDE
6. NO HDMI OUTPUT
No HDMI output.
Replace main board.
Whether the HDMI cable is
connected to the unit.
Connected TV and unit with HDMI cable.
YES
YES
NO
Whether the TV display mode
or resolution is OK?
Adjust the TV display setting.
YES
NO
7. CANNOT READ DISC OR TRAY OPEN/CLOSE
Cannot read disc or tray open/close.
Scan the new barcode.
Whether the loader running
is normal?
Check cable connection of XP3/ XP4/ XP5.
YES
YES
NO
Whether 8.2 V from Q9 S
polarity is normal?
Whether another loader
running is normal?
Replace U11.
Replace main board.
Replace the loader.
YES
YES
NEXT
NO
NO

LG BP340 Specifications

General

Depth	198 mm
Width	259 mm
Height	38 mm
Weight	997 g
Full HD	No
Device type	Blu-Ray player
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS 2.0, DTS-HD Master Audio
Package weight	1270 g
Video upscaling	Yes
Disc types supported	BD, BD-R, BD-RE, CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Card reader integrated	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio formats supported	AAC, FLAC, LPCM, MP3, WMA
Video formats supported	3GP, AVC, AVCHD, DAT, FLV, M4V, MKV, MOV, MP4, MPEG1, MPEG2, MPEG4, TS, VC-1, VOB, WMV
Power consumption (standby)	0.5 W
Power consumption (typical)	12 W
Audio output channels	- channels
