LG BP340 Service Manual

3-9
ELECTRICAL TROUBLESHOOTING GUIDE
8. CANNOT READ USB DEVICE CONTENT
Cannot read USB device content.
Replace main board.
Whether the 5 V on front
board XP1 pin8 is OK?
Fix the connection XP1 on front board
to XP1 on main board.
YES
YES
NO
Whether USB socket on front
board is normal?
Replace USB socket P1.
YES
NO
9. CANNOT CONNECT TO WIRELESS NETWORK
Cannot connect to wireless network.
Replace main board.
Whether Wi-Fi module is
connected to the unit?
Fix the connection XP1 on front board
to XP1 on main board.
YES
YES
NO
Whether Wi-Fi module
connected cable is OK?
Whether Wi-Fi module is OK?
Replace the Wi-Fi module connected cable.
Replace Wi-Fi module.
YES
YES
NO
NO
