LG BP340 Service Manual

3-10
WAVEFORMS ON SYSTEM TEST
1. POWER ON SYSTEM RESET SEQUENCE
RESET active high must delay basis on all system power.
1
2
RESET_
1.2V
1
RESET
RESET_
VCC
3.3V_STBY
RESET_RESET_
R177
100
R177
100
R179
10K
R179
10K
R181
12K
R181
12K
Q1
NPN_3DG3904M
Q1
NPN_3DG3904M
R182
2.7K
R182
2.7K
C214
4.7UF/10V/X
5R
C214
4.7UF/10V/X
5R
Q4
NPN_3DG3904M
Q4
NPN_3DG3904M
R176
3.3K
R176
3.3K
2
1.2V
2. SYSTEM 27 MHz CLOCK WAVEFORM
MT8551 require nominal frequency 27 MHz, tolerance ±30 ppm.
3
27MHz
3
NS_XTALI
AVDD33_VDAC_R
NS_XTALO
AVDD33_PLLGP
AVDD33_VDAC
3.3V
3.3V_STBY
3.3V
U1CU1C
AVDD33_VDAC
E16
AVSS33_VDAC
G14
AVDD33_VDAC_R
D16
AVSS33_VDAC_R
F14
AVDD33_PLLGP
C12
AVSS33_PLLGP
C13
NS_XTALI
A11
NS_XTALO
B11
A
A
C87 33pF/50V/NP0C87 33pF/50V/NP0 R43 10R43 10
R41
1M
R41
1M
C86 33pF/50V/NP0C86 33pF/50V/NP0
Y1
27MHz/30PPM
Y1
27MHz/30PPM
Figure 1-1. Waveform
Figure 2-1. Waveform
Figure 1-2. Test Point
Figure 2-2. Test Point
