Timing Mode Table
The projector can display several resolutions. The following table outlines the resolutions that can be
displayed by the projector.
SIGNAL RESOLUTION
H-SYNC
(KHZ)
V-SYNC
(HZ)
COMPOSITE
/ S-VIDEO
COMPONENT RGB
NTSC — 15.734 60.0 O — —
PAL/SECAM — 15.625 50.0 O — —
640 x350* 31.5 70.0 — — O
640 x350* 37.9 85.0 — — O
640 x400* 37.9 85.0 — — O
640 x 480 31.5 60.0 — — O
640 x 480 37.9 72.0 — — O
640 x 480 37.5 75.0 — — O
640 x 480 43.3 85.0 — — O
800 x 600 35.2 56.0 — — O
800 x 600 37.9 60.0 — — O
800 x 600 48.1 72.2 — — O
800 x 600 46.9 75.0 — — O
800 x 600 53.7 85.0 — — O
1024 x 768 48.4 60.0 — — O
1024 x 768 56.5 70.0 — — O
1024 x 768 60.0 75.0 — — O
1024 x 768 68.7 85.0 — — O
1440 x 900 55.6 60.0 — — O
1280 x 1024 63.98 60.0 — — O
1280 x 1024 79.98 75.0 — — O
1400 x 1050# 65.3 60.0 — — O
VESA
1400 x 1050# 64.7 60.0 — — O
640 x 480 34.98 66.66 — — O
640 x 480 35.0 66.68 — — O
832 x 624 49.725 74.55 — — O
1024 x 768 60.24 75.0 — — O
Apple Macintosh
1152 x 870 68.68 75.06 — — O
480i 15.734 60 — O —
SDTV
576i 15.625 50 — O —
480p 31.469 60 — O —
EDTV
576p 31.25 50 — O —
