LG CA09AWR - Before Use

Air inlet vents
Air outlet vents
Base plate
Coolant piping
Connection
wire
Drain hose
BEFORE USE
Components
Outdoor unit
Operation
lamp
Signal Receiver
ON/OFF button
Air inlet
Air filter
Front grille
Vertical louver
Anti-allergy filter
Air outlet
Horizontal
vane
Triple filter
NOTE
!
• The number of operation lamps and their locations may vary, depending on the model of
the air conditioner.
• The feature can be changed according a type of model.
NOTE
!
• The feature can be changed according a type of model.
7
BEFORE USE
ENGLISH
Indoor unit
