Appendix 39
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption
Refer to the main label on the unit.
Networked standby : 0,5 W
(If all network ports are activated.)
Dimensions (W x H x D) Approx. 350 mm x 163 mm x 251 mm
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 60 %
Inputs
Analog audio in (AUX IN) 1.0 Vrms (1 kHz, 0 dB), 75 Ω, RCA jack (L, R)
Portable in (PORT.IN) 500 mVrms (3.5 mm stereo jack) x 1
Microphone (MIC) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 100 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 75 dB
Bus Power Supply (USB)
5 V 0 500 mA
Amplier (RMS Output power)
Total output 720 W RMS
Front 240 W RMS X 2 (3 Ω at 1 kHz, 20 % THD)
Subwoofer 240 W RMS (3 Ω at 60 Hz, 20 % THD)
y Design and specications are subject to change without notice.
CJ45-DB.DGBRLLZ_WEB_MFL69713058.indd 39 2017-05-10 10:56:49
