Appendix 21
Appendix
5
Specifications
General
Power supply Refer to the main label.
Power consumption Refer to the main label.
Net Weight
1.7 kg
External dimensions (W x H x D) 150 X 200 X 256 mm
Operating conditions Temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 85 %
Bus Power Supply DC 5 V
0
1 A
Inputs
PORT. IN 0.7 Vrms (3.5 mm stereo jack)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Ampli er
Output Power 5 W + 5 W
T.H.D 10 %
CD
Frequency Response 40 Hz to 20 kHz
Signal-to-noise ratio 70 dB
Dynamic range 55 dB
Speakers
Type 1way 1speaker.
Impedance 6 Ω
Rated Input Power 5 W
Max. Input Power 10 W
Net Dimensions (WxHxD) 132 X 200 X 141 mm
Net Weight(1EA)
0.8 kg
Design and speci cations are subject to change without notice.
