E.S.P. setting value (reference)
Table 1
ABNH24GHLA2
ABNH18GHLA2
Setting Value
Static Pressure[mmAq(Pa)]
2.5(25) 4(39) 6(59) 8(78)
100 12.8 - - -
105 13.9 - - -
110 15.2 12.7 - -
115 16.5 14.0 - -
120 17.8 15.3 12.7 -
125 - 16.5 14.0 -
130 - 17.8 15.3 12.6
135 - - 16.5 13.5
140 - - 17.5 14.5
145 - - - 16.5
Setting Value
Static Pressure[mmAq(Pa)]
2.5(25) 4(39) 6(59) 8(78)
105 13.9 - - -
110 15.2 12.7 - -
115 16.5 14.0 - -
120 17.8 15.3 12.7 -
125 - 16.5 14.0 -
130 - 17.8 15.3 12.6
135 - - 16.5 13.5
140 - - 17.6 14.5
145 - - - 16.5
150 - - - 18.0
(Unit: CMM)
(Unit: CMM)
ABNH30GGLA2
Setting Value
Static Pressure[mmAq(Pa)]
4(49) 6(59) 8(78) 10(98)
100 20.8 - - -
105 23.2 19.5 - -
110 26.0 21.5 - -
115 - 23.5 19.1 -
120 - 26.3 21.6 -
125 - - 24.0 19.9
130 - - 27.0 22.7
135 - - - 25.9
140 - - - -
(Unit: CMM)
