Part 2 Functions & Controls
NOTE
1. Be sure to set the value refering table 1. Unexpected set value will cause mal-function.
2. Table 1 is based at 230V. According to the fluctuation of voltage, air flow rate varies.
3. Factory Set(External Static Pressure) each Model
* If it is zero static pressure, please set value below Maximum value.
Model Step CMM
Static Pressure[mmAq(Pa)]
2(20) 2.5(25) 3(29) 4(39) 6(59) 8(78) 10(98) 12(118) 13(127) 14(137) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
ABNW18GM1A0
LOW137374778893103111
117
120 125 128
MID 14.5 76 77 85 91 97 107 114 121 125 128 131
HIGH 16.5 85 87 90 94 103 110
118
125 128 131 134
ABNW24GM1A0
LOW 14.5 76 77 85 89 97 107 114 121 125 128 131
MID 16.5 85 87 90 94 103 110 118 125 128 131 134
HIGH 18 90 92 95 99 108 115 122 129 132 135 138
Model Step CMM
Static Pressure[mmAq(Pa)]
4(39) 5(49) 6(59) 7(69) 8(78) 9(88) 10(98) 11(108) 12(118) 13(127) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
ABNW36GM2A0
LOW 24 88 91 95 100 101 108 113 115 118 118 118
MID 28
93 97 101 105 108 115 118 120 124 124 124
HIGH 32 101 105 109 112 115 119 123 126 128 128 128
Model Step CMM
Static Pressure[mmAq(Pa)]
5(49) 6(59) 7(69) 8(78) 9(88) 10(98) 11(108) 12(118) 13(127) 14(137) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
ABNW42GM2A0
LOW 28 100 103 106 110 114
118
121 125 128 133 136
MID 33 108 111 114 118 122 125 128 131 134 138 141
HIGH 38 117 120 124 127 130 133 135 138 141 144 147
Model Step CMM
Static Pressure[mmAq(Pa)]
2.5(25) 4(39) 5(49) 6(59) 7(69) 8(78) 9(88) 10(98) 11(108) 13(127) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
ABNW30GM1A0
LOW 18 96 102 107 104 114 118 122 125 127 132 134
MID 20 102 110 114 110 121 125
127
130 133 135 137
HIGH 22 110 117 121 118 127 130 133 136 137 138 140
Model Maximum value
ABNW18GM1A0
115
ABNW24GM1A0
ABNW30GM1A0
120
ABNW36GM2A0
ABNW42GM2A0 120
Model Factory set (E.S.P.) mmAq(Pa)
ABNW18GM1A0
6(59)
ABNW24GM1A0
ABNW30GM1A0
ABNW36GM2A0
ABNW42GM2A0
