4.TroubleShooting
3.13 Proximity Sensor on/off TS
Sensor Power: C8400
‐ 29 ‐
VA8500
2
1
VA8501
2
1
4.7KR8400
+1V8_MTK_VIO
+2V8_MTK_VIO
C8400
1u
SDA
1
VDD
8
INT
2
SCL
7
GND
6
LEDK
4
LEDA
5
LDR
3
NC
9
U8400 APDS-9130-200
C8401
1u
VA8502
2
1
COMMON_I2C_SDA
COMMON_I2C_SCLPROXIMITY_INT
R8401
2
1
22
TOL=0.01
Sensor Power: C8400
