1. INTRODUCTION
LGE Internal Use Only
2.3 Main Parts : Solution
Item Part Name Comment
AP Chip MT6582 (MTK)
RF Chip MT6166 (MTK)
2.4HW Features
Item Feature Comment
Form Factor
DOP type
Battery 1) Capacity
Standard : Li-Ion, 2540mAh
2) Packing Type : Changeable
Size
Standard : 138.15 X 70.6 X 10.7
Weight 124g With Battery
Volume 62cc Without Batter
PCB 10 STG Layers , 0.8t
Charging time 4.3hrs
@ Power Off /
2540mAh
RX sensitivity WCDMA(FDD1) : -106.7 dBm
WCDMA(FDD2) : -106.7 dBm
WCDMA(FDD5) : -103.7 dBm
WCDMA(FDD8) : -103.7 dBm
EGSM : -105 dBm
GSM850 : -105 dBm
DCS 1800 : -105 dBm
PCS 1900 : -105 dBm
2.3 Main Parts : Solution
2.4 HW Features
LGE Internal Use Only
2.3 Main Parts : Solution
Item Part Name Comment
AP Chip MT6582 (MTK)
RF Chip MT6166 (MTK)
2.4HW Features
Item Feature Comment
Form Factor
DOP type
Battery 1) Capacity
Standard : Li-Ion, 2540mAh
2) Packing Type : Changeable
Size
Standard : 138.15 X 70.6 X 10.7
Weight 124g With Battery
Volume 62cc Without Batter
PCB 10 STG Layers , 0.8t
Charging time 4.3hrs @ Power Off /
2540mAh
RX sensitivity WCDMA(FDD1) : -106.7 dBm
WCDMA(FDD2) : -106.7 dBm
WCDMA(FDD5) : -103.7 dBm
WCDMA(FDD8) : -103.7 dBm
EGSM : -105 dBm
GSM850 : -105 dBm
DCS 1800 : -105 dBm
PCS 1900 : -105 dBm
