3.2 WCDMA Tx Part
START
Re Ddownload S/W, Cal
WCDMA B1/B2/B5/B8 Tx TEST SET UP
- Test Channel : 10700 / 9800 / 4407 / 3013
- Sector Power : -55 dBm
1.Check
DC Power Supply circuit
2,Check
MT6166 XO
3.Check
PA
4.Check
DPX
5.Check
FEM
There are no Test Points on the IQ Data Line. So It is impossible to check the IQ Data Wave form
3.2.1 WCDMA_Tx B1/B2/B5/B8
