11. DISASSEMBLE GUIDE
- 238 -
Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Take apart the FPCB connector , then separate PCB from Bar Ass’y
4. Disassemble PCB
Take apart the FPCB connector , then separate PCB from Bar Ass’y
4. Disassemble PCB
