11. DISASSEMBLE GUIDE
- 240 -
Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Take apart the connector of Camera main from PCB
Take apart the connector of FPCB_sim from PCB
Take apart the shield can btm from PCB
6. Disassemble PCB Ass’y BTM
Take a
p
art the connector of Camera main from PCB
p
Take apart the connector of FPCB_sim from PCB
Take apart the shield can btm from PCB
6. Disassemble PCB Ass’y BTM
