START
No
DC Power supply Circuit is OK?
Yes
Yes
Check TP1(C1506),TP2(C1504),
TP3(C1505),TP4(C1503)
+1V825_MTK_VRF is OK?
Check TP5(R1506)
+2V8_VTCXO_MTK is OK?
The Problem may be Logic part
Refer to Logic troubleshoot
The Problem may be Logic part
Refer to Logic troubleshoot
No
3.4.1.1 Checking DC Power supply circuit
To Next Page
