LG D337 - Page 81

4. DOWNLOAD
- 81 -
Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Connection OK?
Is the uUSB Cable voltage 4.9V (or 5.0V)
Is it charging properly
After turning on?
START
Yes
Yes
Yes
Yes
Yes
Change I/O connector
Change TA
(or uUSB Cable)
END
END
END
Check the Connection
of uUSB and battery
Change the Charger IC
( U4700 )
Change the Main PCB
No
No
No
No
