Installing the Side Vent Kit
w
WARNING
manual could result in property damage, injury to
persons, or death.
Your new dryer is shipped to vent to the rear.
It can also be configured to vent to the bottom or side
An adapter kit, part number , may be
purchased from your LG retailer. This kit contains the
necessary duct components to change the dryer vent
location.
out the exhaust duct.
OPTION 1: SIDE VENTING
adapter duct onto the blower housing and secure to
the base of the dryer as shown.
faces AWAY from the dryer. Insert the elbow/duct
assembly through the side opening and press it onto
the adapter duct. Secure in place with duct tape.
/
Attach cover plate to the back of the dryer with
included screw.
OPTION 2: BOTTOM VENTING
secure to the base of the dryer as shown.
that the male end of the elbow faces down through
hole in the bottom of the dryer. Secure in place with
duct tape.
Attach the cover plate to the back of the dryer with
included screw.
Rear
Exhaust Duct
Retaining
Screw
Elbow
Cover
Plate
Adapter
Duct
Adapter
Duct
Elbow
Cover
Plate
”
INSTALLATION INSTRUCTIONS
To Next Page
