Top view—On-screen Display (OSD) buttons and LEDs
ITEM LABEL DESCRIPTION
SEE
PAGE:
1.
(POWER)
Turns the projector On or Off
2.
▲ (Up cursor) Navigates and changes settings in the OSD
18
Green Power On
Off Power Off (AC Off) 3.
POWER LED
Flashing Error code
On System over temperature
4.
TEMP LED
Off Normal State
Orange Lamp is ready to be powered-on.
5.
READY LED
Lamp not ready (Warm-up/shutting down/cooling)
(see
Flashing
LED Error Messages on page 37)
6.
MENU Open and exits the OSD buttons
◄ (Left cursor) /
SOURCE/
Detects the input device
Navigates and changes settings in the OSD
187.
▼ (Down cursor) /
VOL./KEYSTONE
Quick Menu – For Keystone, Audio Volume
Navigates and changes settings in the OSD
178.
► (Right cursor) /
AUTO/
Optimizes image size, position, and resolution
Navigates and changes settings in the OSD
7, 189.
– 3 –

LG DS325 Specifications

General

Matrix size	0.55 \
Number of colors	16.78 million colors
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	33.55 - 260 \
Projector native resolution	SVGA (800x600)
Lamp power	200 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focal length range	21.2 - 24.5 mm
HD-Ready	Yes
RMS rated power	1 W
I/O ports	IR, D-sub
Dimensions (WxDxH)	220 x 178 x 71 mm
Power requirements	AC 100 - 240V
Connectivity technology	Wired
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Power consumption (typical)	260 W

Weight and Dimensions

Weight	1450 g
