LG F12U2HDM Series User Manual

7-5. TROUBLESHOOTING WITH ERROR
Inlet
Vavle
Main
PWB
Resistance
[kΩ]
Main
wash
(1) ~ (2)
N
White
A3
~
3
rd
0.8 ~ 1.2
Pre
wash
(1) ~ (2)
NA2 2
nd
~ Gray
0.8 ~ 1.2
Dry
(1) ~ (2)
NA4
~ Yellow
4
rd
0.8 ~ 1.2
Symptom Check Point
1. INLET VALVE
ERROR
1.Check Electric Wiring.
2.Check Inlet valve’s Resistance.
3.Check Inlet valve clogged.
4. Voltage of the inlet valve’s connector.
-. Valve running : 120Vac
±
5%
Auto
mizing



Pre wash
Main wash
Dry BL 1
NA2
NA3
