Introduction
Front Panel/ Back Panel
20
22
21
1.
1
(POWER)
2. VOLUME*
3. FUNC. (FUNCTION)
(FM, AM, DVD/CD, USB, AUX)
4. .(SKIP)
TUN. (-) (TUNER)
5. XTS pro
6.
x
(STOP)
MO./ ST. (MONO/ STEREO)
7. DISC TRAY
8. EQ master/ DEMO button
9. CLOCK button
10. TIMER button
11. SET/ RDS(OPTIONAL) button
12. PHONES
(Headphone jack : 3.5mm)
13. MIC1/ MIC2 (MIC Jacks)
14. USB connector
15. Z (OPEN/CLOSE)
16. > (SKIP)
TUN. (+) (TUNER)
17. XDSS plus / (MP3 Optimizer)
18.
BB
/
[]
(PLAY/PAUSE)
19. Display window
20. Power cord
21. Antenna terminal
22. AUX IN (Auxiliary input) connector
23. COMPONENT VIDEO OUT
(PROGRESSIVE SCAN) connector (Y P
b Pr)
24. VIDEO OUT Jack
25. Speaker terminal
*VOLUME Adjustment
Move your finger around the touch
wheel.
25
24
23
MIC1 MIC2
3
7
6
8
1
2
19
18
14
12
4
5
15
17
16
9
10
11
OPEN
13
