- 11 -
Copyright © 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
(1) Standard Measurement Condition
• Ambient Luminance Level : dark ( < 10 lux)
• Ambient Temperature : Normal Temperature(10ºC ~ 25ºC)
• warm-up Time : More than 30 min (at Full White Pattern)
• Input Signal : VESA 1920 X 1080 @ 60 Hz
• Contrast : 70 (But, the contrast is 100 when we check response time)
• Brightness : Max. 100
• Color Temp : CUSTOM
• Clock/Clock Phase : The Best Setting
(2) Another Spec.: Product Specification Standard( LG(55)G1-1034 )
(3) Cosmetic Spec. : LCD Module IIS Spec.
C
5.1 Display Area
Active area
A
1) Active Display Area of the LCD Monitor Should be within Cabinet’s Bezel.
2) Distance Difference between Active Area and Bezel
A A B
| A-B|<1.0 mm , | C-D|<1.0 mm
A: The Distance from The Left of Active Area to the Bezel
Bezel
B: The Distance from The Right of Active Area to the Bezel
C: The Distance from The Top of Active Area to the Bezel
D: The Distance from The Bottom of Active Area to the Bezel
D
5. Applying module Character
No Item Content Remark
Maker LGD
Type TFT
Active Display Area 23 inches(58.42 cm) diagonal
Pixel Pitch [mm] 0.2652 mm x 0.2652(V) mm
Electrical Interface 2ch-LVDS
Color Depth 6-bit with A-FRC, 16.7M colors
LCD Module
1
Size (Outline) [mm] 527(H) x 309.8 (V) x 8.9 (D) mm
Feature
Hard coating
(3H), Anti-glare treatment of
Surface T
reatment
the front polarizer
Operating Mode Transmissive mode, normally Black
Back light Unit White LED
Typical 14ms
R/T
Max. 25ms
CIE Color
Coordinates
(색 좌표)
