LG Flatron F900B

- 22 -
EXPLODED VIEW PARTS LIST
Part No.
3091TKC095A
6318L19008A
3809TKC045D
3809TKC045A
3043TKK101A
339-002J
4951TKS041H
6140TC2017A
6871TST378A
6174T13010K
6200TJB001N
6850TA9009N
4950TKK450A
6871TUT028A
4951TKK090E
4930TKK031C
332-102E
4815TKT009A
332-102E
3313T19054B
3313T19054D
3313T19054A
6871TMT408B
6871TMT408C
6871TMT408A
332-112F
4001TKK004E
339-008C
332-095B
Description
CABINET ASSEMBLY, F900BJ BRAND TKC075A LGC (ER04) B/A SW
CDT(CIRC), M46QDG423X11NDDD LG-PHILIPS 107KHZ 29.1MM FLATRON TCO V2
BACK COVER ASSEMBLY, FB990G 3808TKC044 PFC/TCO99 - For Euope
BACK COVER ASSEMBLY, FB990G 3808TKC044 BRAND-8C358 - For U.S.A, Canada, Israel, Saudi
TILT SWIVEL ASSEMBLY, FB990G/FB910G TKB059/TKT064 2ND FLAT BRAND
SCREW ASSY, PHP+5*25 (FZMW1)+GW18
METAL ASSEMBLY, FRAME FB990G,PEM NUT BOTTOM FRAME
COIL,DEGAUSSING, - GET 0.6*90T,14 OHM,WITH PURITY FB790G
PWB(PCB) ASSEMBLY,SUB, F900BJ CONTROL TOTAL BRAND .
FBT (FLY BACK TRANSFORMER), FQM19A013,T910BJ(98K) SAMSUNG 19”
FILTER(CIRC),EMC, 02MD5 DELTA BK F900BJ
CABLE,D-SUB, UL20276-9C(5.8MM) AT 1560MM GRAY(85964) T910BJ DM
METAL, REAR BRACKET FB990G
PWB(PCB) ASSEMBLY,USB, F700PJ SUB TOTAL BRAND .
METAL ASSEMBLY, SHIELD BOTTOM-FB990J
HOLDER, PCB FIX, PCT ABS
SCREW,, PTP+4*16(MSWR/FZMY)
SHIELD ASSY, TOP (FB915B)
SCREW,, PTP+4*16(MSWR/FZMY)
MAIN TOTAL ASSEMBLY, F900BJ BRAND CA-130 - For Euope
MAIN TOTAL ASSEMBLY, F900BJ BRAND CA-130 - For U.S.A, Canada
MAIN TOTAL ASSEMBLY, F900BJ BRAND CA-130 - For Israel, Saudi
PWB(PCB) ASSEMBLY,MAIN, F900BJ ALRPE BRAND CA-130 TOTAL - For Euope
PWB(PCB) ASSEMBLY,MAIN, F900BJ ALUSE BRAND CA-130 TOTAL - For U.S.A, Canada, Israel
PWB(PCB) ASSEMBLY,MAIN, F900BJ ALRDE BRAND CA-130 TOTAL - For Saudi, Israel
SCREW,DRAWING, D3.5 L10.0 MSWR/FZMY +SW3.5+RW3.5
SCREW ASSEMBLY, TAPTITE P TYPE D3.0 L10.0 MSWR/FZMY SW3+RW10
SCREW ASSY, MP+3*10(FZMY)+SW3+RW3
SCREW,DRAWING, PZP+3*10(MSWR/FZMY)
Ref. No.
1
2
3
4
5
6
6-1
7
8
9
10
11
12
13
14
15
16
17
A
B
a
b
c
d
