- 23 -
DATE: 2003. 4. 18.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C301 0CK1020K515 1000PF 50V K B TR
C303 0CK3320K515 3300P 50V K B TS
C304 181-288B MKT 100V 104JTR PHS26104
C306 181-288N MKT 100V 103JTR PHS86103
C307 0CK1030K945 0.01UF 50V Z F TR
C308 0CK1040K945 0.1UF 50V Z F TR
C309 0CK1040K945 0.1UF 50V Z F TR
C310 181-288E MKT 100V 474JTR PHS 26474
C311 181-288B MKT 100V 104JTR PHS26104
C312 181-288B MKT 100V 104JTR PHS26104
C313 181-288B MKT 100V 104JTR PHS26104
C315 0CE476CF638 47UF SHL,SD 16V M FM5 TP 5
C317 0CK1040K945 0.1UF 50V Z F TR
C318 0CN1040K949 0.1M 50V Z F TA52
C319 0CK1040K945 0.1UF 50V Z F TR
C320 0CE107CN630 100U SHL 100V M FM5
C321 0CK1040K945 0.1UF 50V Z F TR
C323 0CE107CH638 100UF SHL,SD 25V M FM5 TP 5
C324 0CN1040K949 0.1M 50V Z F TA52
C325 181-288E MKT 100V 474JTR PHS 26474
C328 0CE476CN618 47UF SHL 100V M FL TP5
C330 181-288B MKT 100V 104JTR PHS26104
C331 181-288E MKT 100V 474JTR PHS 26474
C332 181-288E MKT 100V 474JTR PHS 26474
C333 181-288E MKT 100V 474JTR PHS 26474
C334 181-288B MKT 100V 104JTR PHS26104
C335 181-288B MKT 100V 104JTR PHS26104
C339 0CK2710W515 270P 500V K B TS
C340 181-288B MKT 100V 104JTR PHS26104
C341 0CK10302945 0.01UF 2KV Z F TR
C342 0CC2200W415 22PF 500V J NP0 TR
C344 181-288C MKT 100V 224JTR PHS 26224
C346 0CK10202515 1000PF D 2KV 10% TR B(Y5P)
C347 0CK10302940 0.01M 2KV Z F S
C355 0CE476CF638 47UF SHL,SD 16V M FM5 TP 5
C372 0CN1040K949 0.1M 50V Z F TA52
C401 0CC5600K415 56P 50V J NP0 TP
C402 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C403 0CK2710K515 270P 50V K B TS
C404 0CK2710K515 270P 50V K B TS
C405 0CK2710K515 270P 50V K B TS
C406 0CC0400K115 4P 50V D NP0 TS
C407 0CC0400K115 4P 50V D NP0 TS
C410 0CK1040K945 0.1UF 50V Z F TR
C417 0CK1040K945 0.1UF 50V Z F TR
C452 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C453 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C454 0CK1040K945 0.1UF 50V Z F TR
C455 0CK1040K945 0.1UF 50V Z F TR
C456 0CN1040K949 0.1M 50V Z F TA52
C457 181-288E MKT 100V 474JTR PHS 26474
C458 0CK1040K945 0.1UF 50V Z F TR
DATE: 2003. 4. 18.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C459 0CK1010K515 100PF 50V K B TR
C460 0CE475CK638 4.7UF SHL,SD 50V M FM5 TP 5
C601 0CQ6821N419 6800PF 100V J PE NI TP
C602 181-288Q MKT 100V 154JTR PHS26154
C603 0CK1020W515 1000P 500V K B TS
C605 0CE476CN618 47UF SHL 100V M FL TP5
C611 0CE108CH618 1000UF SHL 25V M FL TP5
C701 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C702 0CE3376N650 330M SMS 100V M FM7.5
C704 0CBZTBU003M 562J 20.0*14.0*8.5*10.0 800V
C705 0CE336CN638 33UF SHL,SD 100V M FM5 TP 5
C707 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C708 0CE476CQ618 47U SHL 200V M FL TP5
C709 181-477A 102J 19.5*12.0*7.0*7.5 250V
C710 0CC3300K405 33P 50V J SL TP
C711 0CQ4721N419 0.0047U 100V J POLY NI TP5
C712 0CK2220K515 2200P 50V K B TS
C713 0CE107CH638 100UF SHL,SD 25V M FM5 TP 5
C730 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C731 0CE105CK638 1UF SHL,SD 50V 20% FM5 TP 5
C732 0CK1040K945 0.1UF 50V Z F TR
C734 181-288T MKT 100V 223KTR PHS85223
C735 0CK10302945 0.01UF 2KV Z F TR
C736 0CK10302945 0.01UF 2KV Z F TR
C738 0CE685CN638 6.8UF SHL,SD 100V 20% TP 5 F
C739 0CK1040K945 0.1UF 50V Z F TR
C740 0CE106EK638 10UF KMG 50V M FM5 TP 5
C741 0CC1000W105 10PF 500V D SL TR
C742 0CC1000W105 10PF 500V D SL TR
C743 0CE106CN638 10UF SHL,SD 100V M FM5 TP 5
C744 0CN1020K519 1000P 50V K B TA52
C771 0CK6810K515 680P 50V K B TS
C772 0CK4710W515 470P 500V K B TS
C801 0CQ6821N419 6800PF 100V J PE NI TP
C802 181-288B MKT 100V 104JTR PHS26104
C803 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C804 181-288D MKT 100V 473JTR PHS26473
C805 181-476R 2200 D 100V H PP NI TP5
C806 0CE227CH638 220UF SHL,SD 25V M FM5 TP 5
C807 181-288B MKT 100V 104JTR PHS26104
C808 0CC1000K115 10P 50V D NP0 TS
C809 0CK1020K515 1000PF 50V K B TR
C810 0CE105CK638 1UF SHL,SD 50V 20% FM5 TP 5
C811 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C812 0CE107CH638 100UF SHL,SD 25V M FM5 TP 5
C813 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C814 0CK5610K515 560P 50V K B TS
C815 0CE227CF638 220UF SHL,SD 16V M FM5 TP 5
C817 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C818 181-288J MKT 100V 563JTR PHS26563
C819 181-477U 333J 19.5*13.0*7.5*7.5 250V
C821 0CN1040K949 0.1M 50V Z F TA52
C823 0CK1010K515 100PF 50V K B TR
C832 0CK10102515 100PF D 2KV 10% B(Y5P) TR
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
