DISASSEMBLY
- 9 -
1. TILT/SWIVEL & BACK COVER REMOVAL
1) Set the monitor face downward.
2) Carefully remove the Tilt/Swivel by pulling it upward.
3) Remove two screws (a).
4) Pressing the latch (b), Back cover by pushing it upward. (See Figure. 1)
5) Release the latch (c). (See Figure. 2 and Tip Spec.)
6) Slide the Back Cover away from the Front Cabinet of the monitor.
Back Cover
Cabinet
(c)
Tip
C
B
A
Tip Spec.
A(Width) : 5.0~15.0mm
B(Depth) : 0.6~0.9mm
C(Height) : 12.0mm
Figure. 1
Figure. 2
(b)
(a)
(a)
