LG Flatron F900B

DATE: 2003. 4. 18.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R921 0RD0332Q609 33 1/4W(3 5% TA52
R922 0RD5601Q609 5.60K 1/4W(3 5% TA52
R923 0RD4703Q609 470K 1/4W(3 5% TA52
R924 0RD0152Q609 15 1/4W(3 5% TA52
R925 0RD1501Q609 1.50K 1/4W(3 5% TA52
R926 0RD4701Q609 4.70K 1/4W(3 5% TA52
R927 0RD1001Q609 1K 1/4W(3 5% TA52
R929 0RN0220H609 0.22 1/2W 5% TA52
R930 0RN0220H609 0.22 1/2W 5% TA52
R931 0RC4703A609 470K OHM 1/2 W(7.0) 5% TA52
R932 0RC4703A609 470K OHM 1/2 W(7.0) 5% TA52
R933 0RD0472Q609 47 1/4W(3 5% TA52
R934 0RD3302Q609 33K 1/4W(3 5% TA52
R935 0RD3301Q609 3.30K 1/4W(3 5% TA52
R941 0RD2703Q609 270K 1/4W(3 5% TA52
R949 0RN0220H609 0.22 1/2W 5% TA52
R950 0RD1002Q609 10K 1/4W(3 5% TA52
R951 0RD1101A609 1.1K OHM 1/2 W (7.0) 5% TA52
R952 0RD4701Q609 4.70K 1/4W(3 5% TA52
R953 0RD1002Q609 10K 1/4W(3 5% TA52
R954 0RD4700A609 470 OHM 1/2 W (7.0) 5% TA52
R955 0RD4701Q609 4.70K 1/4W(3 5% TA52
R984 0RX3902J609 39K OHM 1 W 5% TA52
R990 0RD0512Q609 51 1/4W(3 5% TA52
R991 0RD5101Q609 5.10K 1/4W(3 5% TA52
R992 0RD5101Q609 5.10K 1/4W(3 5% TA52
F1 430-858C AFC-520 BAE EUN TA
F2 430-858C AFC-520 BAE EUN TA
F901 0FZZTTH004B TIME LAG HBC TSC 5A/250V,WAL
J315 125-155K BFS3550A0FG SAMWHA 3.5*5.0MM
J54 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM
RL901 6920TBB006A DY3M-DC12V DONGYANG 250VAC 5
SC301 6620TBD003A PCS701E PARK ELEC. 10PIN 14/
SC901 6200TJB001N 02MD5 DELTA BK F900BJ
SG301 6918TAT005E MTAS-201M GIGA AXIAL TAPING
SG302 6918TAT005E MTAS-201M GIGA AXIAL TAPING
SG303 6918TAT005E MTAS-201M GIGA AXIAL TAPING
SG304 6918TAT005E MTAS-201M GIGA AXIAL TAPING
SG305 165-004A AG20PT 152F-L3N/S-23 HANDOK
SG701 165-004A AG20PT 152F-L3N/S-23 HANDOK
SW801 140-079C SLS-1301 SW NON 30 0 HORIZEN
T701 6174T13010K FQM19A013,T910BJ(98K) SAMSUN
T801 6140TDZ010A - - DUMMY,EER2834,F900BJ 80.
T802 6170TCZ008C EI2218 1.48MH FB990G
T901 6170TMZ150A EER4045 200UH V-18PIN F700PJ
TH901 6322B00003A J502P62D070Q290 JA HWA 7 OHM
TH902 6322TA080BA
SCK-084 THINKING 8 OHM 15% 264V - For Israel,Saudi, U.S.A, Canada
VR801 180-035Q EVN-DJAA03B24 (MEC),20KB
VR901 180-035A EVN-DJAA03B12 (MEC),100B
X401 6202TTB003B HC-49/U HARMONY RADIAL 12MHZ
C201 0CN1040K949 0.1M 50V Z F TA52
D201 0DL305029BA LTL-305DJ-0C2 TP LITEON GREE
FB201 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM
P201 6631T20008K 7P H-B 260MM UL1061 AWG 26 T
P250 6602T20009C SMAW200-04 YEONHO 2.0MM LOCK
R201 0RD1001Q609 1K 1/4W(3 5% TA52
DATE: 2003. 4. 18.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R202 0RD1600Q609 160 1/4W(3 5% TA52
R203 0RD2200Q609 220 1/4W(3 5% TA52
R204 0RD2200Q609 220 1/4W(3 5% TA52
R205 0RD1001Q609 1K 1/4W(3 5% TA52
R206 0RD1600Q609 160 1/4W(3 5% TA52
R207 0RD3300Q609 330 1/4W(3 5% TA52
R208 0RD3300Q609 330 1/4W(3 5% TA52
R209 0RD5600Q609 560 1/4W(3 5% TA52
R210 0RD3600Q609 360 1/4W(3 5% TA52
R211 0RD5100Q609 510 1/4W(3 5% TA52
SW201 140-058D SKHV10911A LGEC NON 12 20 HO
SW202 140-058D SKHV10911A LGEC NON 12 20 HO
SW203 140-058D SKHV10911A LGEC NON 12 20 HO
SW204 140-058D SKHV10911A LGEC NON 12 20 HO
SW205 140-058D SKHV10911A LGEC NON 12 20 HO
SW206 140-058D SKHV10911A LGEC NON 12 20 HO
SW250 6600M000020 2216F DAE JIN 30VDC 0.1A 250
C801 0CE1074F638 100UF SRA,SS 16V M FM5 TP 5
C803 0CE1074F638 100UF SRA,SS 16V M FM5 TP 5
C805 0CH6330K416 33PF 50V J NP0 2012 R/TP
C806 0CE1074F638 100UF SRA,SS 16V M FM5 TP 5
C807 0CE1054K638 1 UF SRA,SS 50V M FM5 TP 5
C808 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
C809 0CH6330K416 33PF 50V J NP0 2012 R/TP
C810 0CE1054K638 1 UF SRA,SS 50V M FM5 TP 5
C812 0CH3103K516 10000PF 50V 10% B(Y5P) 2012
C813 0CK1030K945 0.01UF 50V Z F TR
C820 0CH6470K416 47PF 50V 5% NP0 2012 R/TP
C821 0CH6470K416 47PF 50V 5% NP0 2012 R/TP
C822 0CH6470K416 47PF 50V 5% NP0 2012 R/TP
C823 0CH6470K416 47PF 50V 5% NP0 2012 R/TP
C831 0CH6470K416 47PF 50V 5% NP0 2012 R/TP
C832 0CH6470K416 47PF 50V 5% NP0 2012 R/TP
C850 0CH3104K946 100000PF 50V Z F 2012 R/TP
C851 0CH3104K946 100000PF 50V Z F 2012 R/TP
IC801 0IPH112200C ISP1122ABD 32P,LQFP R/TP USB
IC802 0ITI204200B TPS2042ADR TEXAS INSTRUMENT
L801 125-155P BFS2550R2FG SAMWHA 2.5*5.0MM
L802 125-155H BFS3510A0FG SAMWHA 3.5*10MM
L803 971-0054 TIN 50MM TAPING
L804 6210TCE001H HB-1T2012-301JT CERATEC 2012
L805 6210TCE001H HB-1T2012-301JT CERATEC 2012
L807 6210TCE001H HB-1T2012-301JT CERATEC 2012
L808 6210TCE001H HB-1T2012-301JT CERATEC 2012
L809 6210TCE001H HB-1T2012-301JT CERATEC 2012
L810 6210TCE001H HB-1T2012-301JT CERATEC 2012
L812 125-155D BFS3514A0FG SAMHWA 3.5*14MM
R801 0RH1502D622 15K 1/10W 5 D.R/TP
R802 0RH1502D622 15K 1/10W 5 D.R/TP
R803 0RH1502D622 15K 1/10W 5 D.R/TP
R804 0RD0222Q609 22 1/4W(3 5% TA52
R805 0RD0222Q609 22 1/4W(3 5% TA52
R806 0RD0222Q609 22 1/4W(3 5% TA52
R807 0RH1502D622 15K 1/10W 5 D.R/TP
R808 0RH0222D622 22 1/10W 5 D.R/TP
R809 0RH1004D622 1.0M 1/10W 5 D.R/TP
R810 0RH1004D622 1.0M 1/10W 5 D.R/TP
R811 0RH1003D622 100K 1/10W 5 D.R/TP
R812 0RH1003D622 100K 1/10W 5 D.R/TP
- 28 -
OTHERs
CONTROL BOARD
USB BOARD
