LG Flatron LCD 575LE

MODEL: (LM565D-EA), (LB565D-EA), (LB565C-EA) DATE: 2001. 7. 19.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R37 0RJ2701D677 2.7K OHM 1/10 W 5% 1608 R/TP
R38 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R40 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R41 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R42 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R43 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R44 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R45 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R47 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R48 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R49 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R51 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R52 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R53 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R54 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R55 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R60 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R61 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R64 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R65 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R67 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R68 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R69 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R70 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R72 0RJ1004D677 1000000 OHM 1/10 W 5% 1608 R/T
R73 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R74 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R75 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R78 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R79 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R80 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R81 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R82 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R86 0RJ3602D677 36K OHM 1/10 W 5% 1608 R/TP
R87 0RJ9101D677 9.1K OHM 1/10 W 5% 1608 R/TP
R90 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R91 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R94 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R96 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R97 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R98 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R99 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R100 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R101 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R102 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R103 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R120 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R147 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R148 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R149 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R150 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RA1 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA2 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
J1 6612TAH003A DJ-023 KSD R/ANGLE LB563B
J2 6612TAH002A DC-001 UNITOP DC-001 2.0MM (UN
X1 6202TST003D HC-49/SM5H KONY CHIP 12 MHZ 30
X2 6202TST001A SX-1 SUNNY ,SMS, 14.31818MHZ ,
B1 126-005A PKM13EPP-4002-B0 PKM13EPP-4002
C19 0CH6050K116 5PF 50V D NP0 2012 R/TP
C20 0CH6050K116 5PF 50V D NP0 2012 R/TP
C21 0CH3104K566 0.1UF 50V K X 2012 R/TP
C22 0CH3104K566 0.1UF 50V K X 2012 R/TP
MODEL: (LM565D-EA), (LB565D-EA), (LB565C-EA) DATE: 2001. 7. 19.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C23 0CH6050K116 5PF 50V D NP0 2012 R/TP
C24 0CH6050K116 5PF 50V D NP0 2012 R/TP
C25 0CH3104K566 0.1UF 50V K X 2012 R/TP
C26 0CH6050K116 5PF 50V D NP0 2012 R/TP
C27 0CH3104K566 0.1UF 50V K X 2012 R/TP
C28 0CH6050K116 5PF 50V D NP0 2012 R/TP
C30 0CH3104K566 0.1UF 50V K X 2012 R/TP
C31 0CH3104K566 0.1UF 50V K X 2012 R/TP
C32 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
C33 0CH3104K566 0.1UF 50V K X 2012 R/TP
C34 0CH3104K566 0.1UF 50V K X 2012 R/TP
C35 0CH3104K566 0.1UF 50V K X 2012 R/TP
C36 0CH3103K516 10000PF 50V K B 2012 R/TP
C37 0CH3103K516 10000PF 50V K B 2012 R/TP
C38 0CH3103K516 10000PF 50V K B 2012 R/TP
C39 DCH7106F621 10UF 16V M 3528MM TP(-)
C42 0CH3104K566 0.1UF 50V K X 2012 R/TP
J1 6612TCV002A SHQ8593-01-050 HOSIDEN VERTICA
J2 6612TAV001A HEC0486-01-010 HOSIDEN DC12V 1
J5 6612TCV002A SHQ8593-01-050 HOSIDEN VERTICA
L1 6210TCT002B ACB2012M-300-T TDK , CHIP BEAD
L2 150-985J DR10*12 2MH 0.28MM 220.5T R/CE
LD1 0DL305029BA LTL-305DJ-0C2 TP LITEON GREEN/
Q1 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 G
Q2 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 G
Q3 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 G
Q4 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 G
Q5 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 G
Q6 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 G
Q8 0TR102009AJ KRC102S NPN SOT-23 TP KEC
Q9 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 G
Q10 0TR102009AJ KRC102S NPN SOT-23 TP KEC
Q11 0TR102009AJ KRC102S NPN SOT-23 TP KEC
Q12 0TR102009AJ KRC102S NPN SOT-23 TP KEC
Q13 0TR102009AJ KRC102S NPN SOT-23 TP KEC
Q14 0TR102009AJ KRC102S NPN SOT-23 TP KEC
Q15 0TR102009AJ KRC102S NPN SOT-23 TP KEC
Q16 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 G
Q17 0TR102009AJ KRC102S NPN SOT-23 TP KEC
Q18 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 G
Q19 0TR102009AJ KRC102S NPN SOT-23 TP KEC
R1 0RH4701D622 4.7K 1/10W 5 D.R/TP
R2 0RH1000D622 100 1/10W 5 D.R/TP
R3 0RH1000D622 100 1/10W 5 D.R/TP
R19 0RH2402D622 24K OHM 1 / 10 W 2012 5.00% D
R20 0RH2402D622 24K OHM 1 / 10 W 2012 5.00% D
R21 0RH3902D622 39K 1/10W 5 D.R/TP
R22 0RH4702D622 47K 1/10W 5 D.R/TP
R23 0RH1002D622 10K OHM 1 / 10 W 2012 5.00% D
R24 0RH1002D622 10K OHM 1 / 10 W 2012 5.00% D
R25 0RH2402D622 24K OHM 1 / 10 W 2012 5.00% D
R26 0RH2402D622 24K OHM 1 / 10 W 2012 5.00% D
R27 0RH2402D622 24K OHM 1 / 10 W 2012 5.00% D
R28 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R29 0RH3602D622 36K 1/10W 5 D.R/TP
R30 0RH1002D622 10K OHM 1 / 10 W 2012 5.00% D
R31 0RH1002D622 10K OHM 1 / 10 W 2012 5.00% D
R32 0RH2402D622 24K OHM 1 / 10 W 2012 5.00% D
R33 0RH2402D622 24K OHM 1 / 10 W 2012 5.00% D
R34 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R35 0RH3902D622 39K 1/10W 5 D.R/TP
R36 0RH3002D622 30K 1/10W 5 D.R/TP
R37 0RH1002D622 10K OHM 1 / 10 W 2012 5.00% D
R38 0RH1002D622 10K OHM 1 / 10 W 2012 5.00% D
R39 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R41 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
- 25 -
OTHERs
CONTROL BOARD
