LG Flatron LCD 575LE

DISASSEMBLY
1. TILT/SWIVEL REMOVAL
(1) Remove speaker from the Monitor.
(Push the speaker in arrow direction.)
(2) Remove two screws (a).
(3) Remove the Tilt/swivel.
2. BACK COVER REMOVAL
(1) Remove four screws (a) from the Back Cover.
(2) Remove the Back Cover.
3. TOP SHIELD REMOVAL
(1) Remove seven screws (a).
(2) Remove the Top Shield and Interface Shield.
(a)
(a)
Back Cover
(a)
(a)
(a)
(a)
(a)
(a)
(a)
(a)
- 8 -
