LG Flatron M1717A

- 22 -
DATE: 2005. 10. 21.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C101 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C102 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C103 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C104 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C105 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C106 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C107 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C109 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C126 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C127 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C129 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C130 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C131 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C132 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C134 0CE228ED618 "2200UF KMG,RD 10V 20% FL TAP"
C141 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C144 0CK105DH56A 1UF 2012 25V 10% X7R R/TP
C145 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C146 0CE108EH618 1000UF KMG 25V 20% FL TP 5
C150 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C153 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C154 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C155 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C156 0CH6680K416 68PF 2012 50V 5% NP0 R/TP
C157 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C158 0CE105WK6DC 1UF MVK 50V 20% R/TP(SMD) SM
C170 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C171 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C172 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C174 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C175 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C176 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C177 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C178 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C180 0CK475DD57A 4.7UF 2012 10V 10% X5R R/TP
C181 0CK475DD57A 4.7UF 2012 10V 10% X5R R/TP
C187 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C188 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C189 0CC271CK41A 270PF 1608 50V 5% R/TP NP0
C190 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C191 0CH6331K416 330PF 2012 50V 5% NP0 R/TP
C192 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C194 0CH8106F691 10UF 16V 20% 105STD (CYL) R/
C195 0CH8106F691 10UF 16V 20% 105STD (CYL) R/
C196 0CH8106F691 10UF 16V 20% 105STD (CYL) R/
C197 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C198 0CC271CK41A 270PF 1608 50V 5% R/TP NP0
C199 0CC271CK41A 270PF 1608 50V 5% R/TP NP0
C201 0CH8476H691 47UF 25V 20% 105STD (CYL) R/
C202 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C203 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C204 0CC221CK41A 220PF 1608 50V 5% R/TP NP0
DATE: 2005. 10. 21.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C205 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V) 2"
C206 0CK224CF56A 0.22UF 1608 16V 10% R/TP X7R
C207 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
C208 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
C209 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V) 2"
C210 0CK224CF56A 0.22UF 1608 16V 10% R/TP X7R
C211 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C212 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C213 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V) 2"
C214 0CK224CF56A 0.22UF 1608 16V 10% R/TP X7R
C215 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V) 2"
C216 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C217 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C218 0CK224CF56A 0.22UF 1608 16V 10% R/TP X7R
C220 0CE337SC6D8 "330UF MVG,MC,VC 6.3V 20% SMD"
C221 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C222 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C223 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
C224 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C225 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C226 0CE477EH618 470UF KMG 25V 20% FL TP 5
C227 0CE477EH618 470UF KMG 25V 20% FL TP 5
C228 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V) 2"
C232 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C233 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C236 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C237 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C238 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C239 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C240 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V) 2"
C3001 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3002 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3004 0CH8106F691 10UF 16V 20% 105STD (CYL) R/
C301 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C3011 0CH3103K516 10000PF 50V 10% B(Y5P) 2012
C3012 0CH6470K416 47PF 2012 50V 5% NP0 R/TP
C3013 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3014 0CH6470K416 47PF 2012 50V 5% NP0 R/TP
C3015 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C3017 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C3019 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C302 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C3022 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V) 2"
C3024 0CH6470K416 47PF 2012 50V 5% NP0 R/TP
C3026 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V) 2"
C3028 0CH6470K416 47PF 2012 50V 5% NP0 R/TP
C303 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C3030 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C3031 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C3032 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/T"
C3033 0CH6470K416 47PF 2012 50V 5% NP0 R/TP
C3035 0CK225DH94A "2.2UF 2012 25V 80%,-20% F(Y5"
C3036 0CK333CK56A 33000PF 1608 50V 10% R/TP X7
C3037 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
