LG Flatron M1717A

DATE: 2005. 10. 21.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L329 6200J00005E HH-1M2012-601JT CERATEC R/TP
L330 6200J00005E HH-1M2012-601JT CERATEC R/TP
L333 6200J00005E HH-1M2012-601JT CERATEC R/TP
L334 6200J00005E HH-1M2012-601JT CERATEC R/TP
L335 6200J00005E HH-1M2012-601JT CERATEC R/TP
R211 6210TCE0014 HB-1M2012-221 CERATEC R/TP
R212 6210TCE0014 HB-1M2012-221 CERATEC R/TP
R213 6210TCE0014 HB-1M2012-221 CERATEC R/TP
R214 6210TCE0014 HB-1M2012-221 CERATEC R/TP
U701 6200QL3003A K3965D EPCOS BULK PAL VIDEO(
U702 6200QL3003B K9656D EPCOS BULK PAL SOUND(
L704 0LC0562001A 0.56UH 10% 2012 R/TC FI-A201
L731 0LC1020101A 1UH 10% 2012 R/TC FI-B2012-1
Q101 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q102 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q103 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q105 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q106 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q107 0TR162309CA KSC1623 TP SAMSUNG SOT23 NP
Q108 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q109 0TR390609FA FAIRCHILD KST3906-MTF TP SOT
Q110 0TR162309CA KSC1623 TP SAMSUNG SOT23 NP
Q111 0TR162309CA KSC1623 TP SAMSUNG SOT23 NP
Q112 0TR162309CA KSC1623 TP SAMSUNG SOT23 NP
Q113 0TR162309CA KSC1623 TP SAMSUNG SOT23 NP
Q114 0TR162309CA KSC1623 TP SAMSUNG SOT23 NP
Q115 0TR162309CA KSC1623 TP SAMSUNG SOT23 NP
Q116 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q117 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q201 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q203 0TR162309CA KSC1623 TP SAMSUNG SOT23 NP
Q301 0TR127009AA KTA1270-Y(KTA562TM) TP KEC T
Q302 0TR127009AA KTA1270-Y(KTA562TM) TP KEC T
Q304 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q305 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q402 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q701 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q702 0TR388109AA KTC3881 CHIP TP KEC - -
Q704 0TR162309CA KSC1623 TP SAMSUNG SOT23 NP
Q715 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
U405 0TFVI80023A VISHAY SI3865DV R/TP TSOP-6
U406 0TF492509AA SI4925DY TP TEMIC 30V 6.1A S
R1001 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R1002 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1003 0RJ1300D477 130 OHM 1/10 W 1% 1608 R/TP
R1004 0RJ0752D477 75 OHM 1/10 W 1% 1608 R/TP
R1005 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R1006 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1007 0RJ1300D477 130 OHM 1/10 W 1% 1608 R/TP
R1008 0RJ0752D477 75 OHM 1/10 W 1% 1608 R/TP
R1009 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R1010 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1011 0RJ1300D477 130 OHM 1/10 W 1% 1608 R/TP
R1012 0RJ0752D477 75 OHM 1/10 W 1% 1608 R/TP
R1013 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R1014 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
DATE: 2005. 10. 21.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R1017 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R1018 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R102 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R1020 0RH5102D622 51K OHM 1 / 10 W 2012 5.00%
R1021 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R1022 0RH1802D622 18K OHM 1 / 10 W 2012 5.00%
R1026 0RH7500D622 750 OHM 1 / 10 W 5% D R/TP
R1027 0RH7500D622 750 OHM 1 / 10 W 5% D R/TP
R1028 0RH7500D622 750 OHM 1 / 10 W 5% D R/TP
R1029 0RH7500D622 750 OHM 1 / 10 W 5% D R/TP
R103 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R1030 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R1031 0RH0752D622 75 OHM 1 / 10 W 2012 5.00% D
R1032 0RH0752D622 75 OHM 1 / 10 W 2012 5.00% D
R1033 0RH0752D622 75 OHM 1 / 10 W 2012 5.00% D
R1034 0RH0752D622 75 OHM 1 / 10 W 2012 5.00% D
R1039 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R104 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R1040 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R1041 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R1043 0RH1003D622 100K OHM 1 / 10 W 2012 5.00%
R1045 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R1047 0RH1003D622 100K OHM 1 / 10 W 2012 5.00%
R1048 0RH1801D622 1.8K OHM 1 / 10 W 2012 5.00%
R105 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R107 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1070 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R1071 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1072 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R1073 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R1074 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1075 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R1076 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R1077 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R111 0RH1200D622 120 OHM 1 / 10 W 2012 5.00%
R112 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R114 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R115 0RH0222D622 22 OHM 1 / 10 W 2012 5.00% D
R116 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R117 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R118 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R119 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R121 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R122 0RH1501D622 1.5K OHM 1 / 10 W 2012 5.00%
R126 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R128 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R129 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R130 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R131 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R132 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R133 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R134 0RJ1102D677 11K OHM 1/10 W 5% 1608 R/TP
R135 0RJ1102D677 11K OHM 1/10 W 5% 1608 R/TP
R136 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R137 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R138 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R139 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R145 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R146 0RH0472D622 47 OHM 1 / 10 W 2012 5.00% D
R147 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R148 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R149 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
- 25 -
TRANSISTOR
RESISTORs
