LG Flatron M1717A

DATE: 2005. 10. 21.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R383 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R384 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R385 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R386 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R387 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R388 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R391 0RH0331D622 3.3 OHM 1 / 10 W 2012 5.00%
R392 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R394 0RH0331D622 3.3 OHM 1 / 10 W 2012 5.00%
R395 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R396 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00%
R397 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00%
R399 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R401 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R409 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R410 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R411 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R413 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R414 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R417 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R418 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R425 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R426 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R434 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R533 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R534 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R702 0RH4700D622 470 OHM 1 / 10 W 2012 5.00%
R705 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R706 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R711 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R714 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R715 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R720 0RJ1201D677 1200 OHM 1/10 W 5% 1608 R/TP
R728 0RH1501D622 1.5K OHM 1 / 10 W 2012 5.00%
R729 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/T
R740 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R741 0RH4700D622 470 OHM 1 / 10 W 2012 5.00%
R742 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R750 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R751 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R753 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R760 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R761 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R762 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R770 0RJ0562D677 56 OHM 1/10 W 5% 1608 R/TP
R771 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/TP
R772 0RH8200D622 820 OHM 1 / 10 W 2012 5.00%
R773 0RJ3000D677 300 OHM 1/10 W 5% 1608 R/TP
R774 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R775 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R776 0RX0202K665 20 OHM 2 W 5% SF15
TU701 6700VS0003H TAEW-G053P LGIT MULTI FS PHO
U303 6620F00017A CCSD-32T-SM WOOYOUNG 32P PLC
X301 6202TST003G HC-49/SM5H KONY 24.576MHZ +/
SW501 140-058E SKHV10910B LGEC NON 12V 20A
SW502 140-058E SKHV10910B LGEC NON 12V 20A
DATE: 2005. 10. 21.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
SW503 140-058E SKHV10910B LGEC NON 12V 20A
SW504 140-058E SKHV10910B LGEC NON 12V 20A
SW505 140-058E SKHV10910B LGEC NON 12V 20A
SW506 140-058E SKHV10910B LGEC NON 12V 20A
SW507 140-058E SKHV10910B LGEC NON 12V 20A
U501 6712SCA232A TSOP34838SO1 VISHAY 38KHZ LF
C501 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C502 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C504 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
R502 0RJ2201D677 2200 OHM 1/10 W 5% 1608 R/TP
R503 0RJ8200D677 820 OHM 1/10 W 5% 1608 R/TP
R504 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/TP
R505 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/TP
R507 0RJ8200D677 820 OHM 1/10 W 5% 1608 R/TP
R508 0RJ2201D677 2200 OHM 1/10 W 5% 1608 R/TP
ZD502 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323
ZD504 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323
ZD505 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323
LED552 0DLBE0048AA BRIGHT LED ELECTRONICS BL-HK
Q551 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
R551 0RJ1200D677 120 OHM 1/10 W 5% 1608 R/TP
R552 0RJ1200D677 120 OHM 1/10 W 5% 1608 R/TP
R553 0RJ1200D677 120 OHM 1/10 W 5% 1608 R/TP
R554 0RJ1200D677 120 OHM 1/10 W 5% 1608 R/TP
R555 0RJ1200D677 120 OHM 1/10 W 5% 1608 R/TP
R556 0RJ1200D677 120 OHM 1/10 W 5% 1608 R/TP
SW551 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
- 27 -
OTHERs
CONTROL BOARD
